S355J0WP Corrosion Resistant Steel Plate
Want to know more about our products? Please contact us by email or phone.
Gnee Steel (Tianjin) Co., Ltd. is one of the most professional s355j0wp corrosion resistant steel plate manufacturers and suppliers in China. Welcome to wholesale customized s355j0wp corrosion resistant steel plate at competitive price from our factory. Good service and quality products are available.
S355J0WP Corrosion Resistant Steel Plate
S355J0WP steel plate is a European standard atmospheric corrosion resistant steel, a corten steel plate, is a low alloy steel made of adding a certain amount of alloying elements to ordinary steel. The atmospheric corrosion resistance of corten steel plate is 2-8 times that of ordinary carbon steel, and it has good mechanical properties, welding properties, etc., and the longer the time, the more obvious the corrosion resistance effect.
GNEE is a weathering steel plate supplier with 16 years of production experience. The weathering steel plates we provide are strictly produced in accordance with the standards, passed the quality certification, can provide quality certificates, and accept third-party testing.
We can not only provide corrosion-resistant steel plates of various specifications and sizes, but also A243 weathering steel pipes. In addition, the products we provide can also provide size customization and various processing services according to your end-use needs.
S355J0WP Atmospheric Corrosion Steel Plate Chemical Composition and Mechanical Property
|
Grade |
Chemical Composition (%) |
||||
|
C |
Mn≥ |
Si |
P |
S |
|
|
EN10155 S355J0WP |
0.16 |
0.5-1.5 |
0.5 |
0.035 |
0.035 |
|
Grade |
Mechanical Property |
||||
|
Tensile Strength (MPa) |
Yield Strength (MPa) |
% Elongation in 2 in. (50mm) min |
Impacting Test Temperature (°C) |
||
|
EN10155 S355J0WP |
510 |
355 |
19 |
+20, 0, -20 |
|
S355J0WP atmospheric corrosion resistant steel Product Information
| Product Name | Corten Sheet plate | |
| Standard | ASTM standard | A588 Grade A,A588 Grade B,A709 Grade 50W,Corten A,Corten B,etc. |
| ASME standard | SA588 Grade A,SA588 Grade B,SA709 Grade 50W,etc. | |
| EN standard | S355J0WP,S355J2WP,S355J0W,S355J2W,S355K2W,etc. | |
| JIS standard | SPA-H,SPA-C,etc. | |
| GB standard | Q295GNH,Q345GNH,Q295NH,Q355NH,09CuPCrNi-A,09CuPCrNi-B,etc. | |
| Thickness | 1-200mm or as required | |
| Length | 3000-12000mm as required | |
| Technique | hot rolled cold rolled (as custom's request) | |
| Surface Treatment | Clean, finishing,blasting cording to customer requirement | |
| Tolerance | ±1% | |
| Processing Services | Welding, Punching, Cutting,Decoiling | |
| Invoicing | by theoretical weight | |
| Delivery Time | Within 7-14 days | |
| Packing | Standard Packing | |
S355J0WP weathering steel Additional Condition
UT (Ultrasonic examination), AR (As Hot Rolled only), TMCP (Thermal Mechanical Control Processing), N (Normalized), Q+T (Quenched and Tempered), Z Direction Test (Z15, Z25, Z35), Charpy V-Notch Impact Test, HIC test, NDT, PWHT (Simulated Post Weld Heat Treatment), NACE0175, The Third Party Test (Such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
A) Packaging Details: Standard export seaworthy packing or as required.
B) Delivery Time: 30-50 days, 7 days for stock goods.
C) Loading Port: Shanghai, Tianjin, Qingdao.
D) Offer Ability: 5000MT/Per Month.
E) MOQ: 1 Pcs.
Weathering process of weathering steel
S355J0WP Corrosion Resisting Structural Steel Products Product images
GNEE Group team photo
GNEE Group Customer visit
Our products have undergone strict quality testing, and equipped with professional certificates, if you have any questions about S355J0WP Corten steel plate, welcome to check.
