A203GrB Steel Plates For Pressure Vessels

Gnee Steel (Tianjin) Co., Ltd. is one of the most professional a203grb steel plates for pressure vessels manufacturers and suppliers in China. Welcome to wholesale customized a203grb steel plates for pressure vessels at competitive price from our factory. Good service and quality products are available.



A203GrB Steel plates for pressure vessels



‌A203GrB boiler plate is a nickel alloy steel plate specially made for pressure vessels and also suitable for boiler manufacturing. ‌A203GrB boiler steel plate has good high strength, corrosion resistance and weldability, and is widely used in the manufacture of pressure vessels and boilers in industries such as petroleum, chemical, and power stations.



‌A203GrB vessel plate usually implements ASTM A203/A203M or ASME SA203/SA203M standards, and the delivery state is generally normalized or normalized and tempered. GNEE can also choose the delivery method according to your technical requirements.



The thickness range of A203GrB boiler steel is usually between 8-150mm, and the width and length can be customized according to specific needs. In addition, these steel plates can also be processed and customized according to the specific requirements of customers to meet the needs of different application scenarios.





Product Name	Boiler vessel plate
Technology	Hot Rolled
Standard	GB713: Q245R, Q345R, Q370R, 18MnMoNbR, 13MnNiMoR, 15CrMoR, 14Cr1MoR, 12Cr2Mo1R, 12Cr1MoVR, etc. GB19189: 07MnCrMoVR, 07MnNiCrMoVDR, 12MnniVR, etc. GB3531: 16MnDR, 09MnNiDR, 15MnNiDR, etc. JIS G3103: SB410, SB450, SB480, etc. JIS G3115: SPV235, SPV315, SPV355, SPV410, SPV450, SPV490, etc. (ASME) ASTM: (S)A299M; (S)A515M Gr. 60, 65, 70; (S)A204M(A,B,C), (S)A387M Gr (5, 11, 12, 22), (S)A537M(Cl. 1, Cl. 2), (S)A533Gr.B, (S)A517M Gr. (B, F), (S)A516M Gr (60, 65, 70), (S)A662M(A, B, C), (S)A302MGr (A, B, C, D), (S)A737M Gr (A,B,C), (S)A738M Gr (A,B, C), (S)A203(A, B, D, E, F), (S)A285(A, B, C), (S)A841Gr. D, etc. EN10028-2: P235GH,P265GH,P295GH,P355GH,16Mo3,13CrMo4-5, 10CrMo9-10,11CrMo9-10,etc. EN10028-3: P275(NH,NL1,NL2),P355(N, NH,NL1,NL2), P460(NH, NL1,NL2), etc.
Width	0.6m-3m or as required
Length	4m-12m or as required
Thickness	3mm-300mm or as required
Surface Treatment	Clean, blasting and painting according to customer requirement
Package	Export standard packaging: bundled wooden box or required





♦ High tension test
♦ Low temperature impacting test
♦ Simulated post-welded heat treatment (PWHT)
♦ Rolling under standard NACE MR-0175 (HIC+SSCC)
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user's demands





Thickness(mm)	C	Si	Mn	P	S	Ni
T≤50	0.21	0.15-0.40	0.70	0.035	0.035	2.10-2.50
50<T	0.24		0.80





Yield strength (≥Mpa)	Tensile strength (Mpa)	Elongation in ≥,%
275	485-620	200mm	50mm
		17	21















We support multi-specification, multi-brand weather resistant steel plate customization, if you have A203GrB steel plates for pressure vessels or other corten steel plate product customization needs, please contact us!
