A517GrB High-Strength Alloy Pressure Vessel Steel Plate

Gnee Steel (Tianjin) Co., Ltd. is one of the most professional a517grb high-strength alloy pressure vessel steel plate manufacturers and suppliers in China. Welcome to wholesale customized a517grb high-strength alloy pressure vessel steel plate at competitive price from our factory. Good service and quality products are available.



A517GrB High-Strength Alloy Pressure Vessel Steel Plate

‌A517GrB boiler plate is a high-strength, low-alloy steel plate material with good mechanical properties and a wide range of applications. ‌

‌Construction field‌: A517GrB vessel plate is often used to make large steel structures, such as the load-bearing structure of bridges and the frame of high-rise buildings.



‌Shipbuilding field‌: Ships need to operate in various harsh sea conditions, and the corrosion resistance and strength of materials are extremely high. A517GrB boiler plate can meet these requirements, allowing ships to maintain structural integrity and safety during long sea voyages. ‌



Pressure vessel manufacturing field‌: The design and manufacture of pressure vessels need to consider the pressure bearing capacity and safety performance of the container. The high strength and excellent toughness of A517GrB boiler steel plate have this feature.



‌In addition, A517GrB pressure vessel plate is also widely used in the fields of petroleum, chemical machinery, gas storage, thermal power generation, etc. to make large-scale heavy equipment.





Product Name	Pressure Vessel Steel Plate
Standard	GB713: Q245R, Q345R, Q370R, 18MnMoNbR, 13MnNiMoR, 15CrMoR, 14Cr1MoR, 12Cr2Mo1R, 12Cr1MoVR, etc. GB19189: 07MnCrMoVR, 07MnNiCrMoVDR, 12MnniVR, etc. GB3531: 16MnDR, 09MnNiDR, 15MnNiDR, etc. JIS G3103: SB410, SB450, SB480, etc. JIS G3115: SPV235, SPV315, SPV355, SPV410, SPV450, SPV490, etc. (ASME) ASTM: (S)A299M; (S)A515M Gr. 60, 65, 70; (S)A204M(A,B,C), (S)A387M Gr (5, 11, 12, 22), (S)A537M(Cl. 1, Cl. 2), (S)A533Gr.B, (S)A517M Gr. (B, F), (S)A516M Gr (60, 65, 70), (S)A662M(A, B, C), (S)A302MGr (A, B, C, D), (S)A737M Gr (A,B,C), (S)A738M Gr (A,B, C), (S)A203(A, B, D, E, F), (S)A285(A, B, C), (S)A841Gr. D, etc. EN10028-2: P235GH,P265GH,P295GH,P355GH,16Mo3,13CrMo4-5, 10CrMo9-10,11CrMo9-10,etc. EN10028-3: P275(NH,NL1,NL2),P355(N, NH,NL1,NL2), P460(NH, NL1,NL2), etc.
Size	custom made
Package	Clean, blasting and painting according to customer requirement





♦ High tension test
♦ Low temperature impacting test
♦ Simulated post-welded heat treatment (PWHT)
♦ Heat treatment under Quenching and Tempering
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user's demands
♦ Rolling under ASTM A20/A20M for Genenal requirements of pressure vessel used steel





C	Si	Mn	P	S	B	Cr	Mo	Ti	V
0.15-0.21	0.15-0.35	0.70-1.00	0.035	0.035	0.0005-0.005	0.40-0.65	0.15-0.25	0.01-0.04	0.03-0.08





Thickness (mm)	Yield strength (≥Mpa)	Tensile strength (Mpa)	Elongation in ≥,%
			50mm
T≤65	690	795-930	16
65<T	620	725-930	14















We support multi-specification, multi-brand weather resistant steel plate customization, if you have A517GrB high-strength alloy pressure vessel steel plate or other corten steel plate product customization needs, please contact us!
