P265GH Boiler Plate
Want to know more about our products? Please contact us by email or phone.
Gnee Steel (Tianjin) Co., Ltd. is one of the most professional p265gh boiler plate manufacturers and suppliers in China. Welcome to wholesale customized p265gh boiler plate at competitive price from our factory. Good service and quality products are available.
P265GH Boiler Plate
P265GH steel plate is a European standard steel plate for pressure vessels, the specification is EN10028, with good plasticity, resistance, cold bending function and welding function.
P265GH pvq plate is widely used in petroleum, chemical, power station, boiler and other industries, for the production of reactors, heat exchangers, separators, spherical tanks, gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drum, liquefied petroleum gas cylinders, hydropower station high-pressure water pipes, water turbine vortex shells and other equipment and components.
P265GH Vessel Plate Chemical Composition
| CARBON | Silicon | Manganese | PHOSPHORUS | Sulfur |
|---|---|---|---|---|
| 0.25 max | 0.10 - 0.35 | 0.60 - 1.40 | 0.030max | 0.030max |
| CHROMIUM | COPPER | MOLYBDENUM | NICKEL | |
| 0.25 max | 0.30max | 0.10max | 0.30max |
P265GH Boiler Plate Mechanical Property
| Steel Grade | Delivery State | Thickness mm | Yield Strength Mpa≥ | Tensile Strength Mpa |
Elongation %≥ | Minimum Impact Power of Temperature | |||
|---|---|---|---|---|---|---|---|---|---|
| name | number | -20 | 0 | +20 | |||||
| P265GH | 1.0425 | +Nd | ≤16 | 265 | 410~530 | 22 | 27 | 34 | 40 |
| 16<t≤40 | 255 | ||||||||
| 40<t≤60 | 245 | ||||||||
| 60<t≤100 | 215 | ||||||||
| 100<t≤150 | 200 | 400~530 | |||||||
| 150<t≤250 | 185 | 390~530 | |||||||
Steel Boiler Plate Tensile Requirements
| THICKNESS | YIELD STRENGTH MPa | TENSILE STRENGTH | ELONGATION A% |
|---|---|---|---|
| up to 16 millimeter | 265 minimum | 410 MPa to 530 MPa | 22 minimum |
| 16 millimeter to 40 millimeter | 255 minimum | 410 MPa to 530 MPa | 22 minimum |
| Above 40 millimeter to 60 millimeter | 245 minimum | 410 MPa to 530 MPa | 22 minimum |
| Above 60 millimeter to 100 millimeter | 215 minimum | 410 MPa to 530 MPa | 22 minimum |
| Above 100 millimeter to 150 millimeter | 200 minimum | 400 MPa to 530 MPa | 22 minimum |
| Above 150 millimeter to 250 millimeter | 185 minimum | 390 MPa to 530 MPa | 22 minimum |
Boiler Steel Plate Product Iamge


GNEE Group Team Photo

GNEE Group Customer Visit



GNEE Group Steel Exhibitions



We have a good reputation in this area, so we can offer you high quality P265GH boiler plate, our price is also very competitive, if you are interested in our products, please contact us, we look forward to your enquiry.
