S13-20kV-Oil-Immersed Transformer

Gnee Steel (Tianjin) Co., Ltd. is one of the most professional s13-20kv-oil-immersed transformer manufacturers and suppliers in China. Welcome to wholesale customized s13-20kv-oil-immersed transformer at competitive price from our factory. Good service and quality products are available.

GNEE Steel oil immersed type transformer

An oil-immersed transformer, also called Oil filled transformer, is a kind of voltage transformation device utilizing the oil cooling method to reduce the transformer temperature. Unlike the dry type transformer, the body of the Oil-immersed transformer is installed in the welded steel oil tank filled with insulation oil. When an Oil-immersed transformer in operation, the heat of the coil and iron core firstly is transformed into the insulation oil and then to the cooling medium. And according to the capacity sizes, it can be divided into an immersed natural cooling transformer and an immersed forced air cooling transformer.

three phase oil immersed transformer

1)Low loss

The iron core is made of high-quality Hi-B cold-rolled silicon steel sheets, which are cut longitudinally and horizontally using a fully automatic lamination machine. The multi-level fully inclined seam is fully automatic lamination, and the iron core binding adopts the overall pressurization and PET tape binding process, effectively reducing the no-load loss and current of the transformer.

2)Low noise

The noise of oil immersed self cooling transformers is mainly caused by electromagnetic noise from the iron core. In order to reduce the noise, our company has taken the following measures:

Low magnetic flux density design;

High quality high magnetic silicon steel sheet;

Adopting a Swiss fully automatic laminating machine to control the stacking accuracy;

Reliable clamping and support measures;

Special shock absorption measures.

3) No leakage

The oil tank and storage tank have undergone positive and negative pressure leak testing to ensure that there will be no oil leakage during normal operation of the product. The component installation adopts a flange groove structure, which is formed in one go. All sealing components are made of high-quality one-time formed acrylic rubber parts to prevent oil leakage.

4)Strong short-circuit resistance

In order to ensure that the transformer can withstand the impact of short-circuit current and apply rated voltage on the primary side, under the condition of complete short-circuit on the secondary side, without causing thermal and mechanical damage under the action of short-circuit current, our company has taken the following measures during design and manufacturing:

• Reasonably calculate the ampere turn balance of the transformer coil using semi hard copper wire;
• The strength and stiffness of the iron core clamping components are calculated to meet the safety requirements of maximum short-circuit mechanical force;
• The winding pads are uniformly densified and made of high-density hard cardboard;
• The winding adopts a reasonable structure with evenly distributed and compressed compression blocks, with uniform assembly height and uniform stress, ensuring the ability to withstand short circuits;
• Take some special measures to prevent the deformation of the coil under force.

Single Phase Oil Immersed Distribution Transformer

​
