Products Description
ABS AQ63 ship plate is an extra high strength ship plate which owned the minimum yield strength at 620 Mpa.When rolling steel plate ABS Grade AQ63,Quenched and tempered is Ok for these shipbuilding steel plates and sheets.Now Xinsteel Industrial stock ABS AQ63 steel plate from thickness 6-250mm,width from 1500mm-4200mm and length from 3000mm to 18000mm,we also can cut into small sizes in our processing plants if customer requested.
ABS Grade AQ63 Shipbuilding Steel Plate Chemical Composition and Mechanical Property
| C max | Si max | Mn | P max | S max | N max. |
|
0.21 |
0.55 | 1.70 |
0.030 |
0.030 |
0.020 |
| Yield Strength (MPa) min. | Tensile Strength (MPa) | Elongation min. % |
| 620 | 720-890 | 15 |
|
Charpy V-Notch Impact Test |
Thickness: ≦50mm |
Longitudinal (KV2/J) |
27 |
|
Transverse (KV2/J) |
20 |
||
|
Thickness: >50~70 |
Longitudinal (KV2/J) |
34 |
|
|
Transverse (KV2/J) |
24 |
||
|
Thickness: >70~150 |
Longitudinal (KV2/J) |
41 |
|
|
Transverse (KV2/J) |
27 |
||
|
Test Temperature (℃) |
20 |
||
|
Plate Size |
Thickness (mm) |
1.2~130 |
|
|
Width (mm) |
900~4800 |
||
|
Length (mm) |
980~25000 |
||
|
Note |
We can customize plate sizes for you. |
||
ABS Grade AQ63 Shipbuilding Steel Plate Application
ABS Grade AQ63 Shipbuilding steel plate is mainly used to Shipbuilding Project and Ocean Offshore Structural Project.
ABS Grade AQ63 Shipbuilding Steel Plate Other Name
ABS Grade AQ63 Shipbuilding steel plate,ABS Grade AQ63 Ship Steel plate ,ABS Grade AQ63 Marine Steel plate , ABS Grade AQ63 Steel Plate .
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Technical Requirements & Additional Services for ABS AQ63 steel plate:
♦ High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Cetificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user's demands
