Products Description
Weathering steel, that is, atmospheric corrosion-resistant steel, is a low-alloy steel series between ordinary steel and stainless steel. Weathering steel is made of ordinary carbon steel with a small amount of corrosion-resistant elements such as copper and nickel. Compared with ordinary carbon steel, weathering steel has better corrosion resistance in the atmosphere.
Weathering steel is often used in riveted and welded structural parts for vehicles, containers, buildings and other structures. When used as welded structural parts, the thickness of the steel is less than 16 mm. The welding performance of weathering steel for welded structure is better than that of high weathering structural steel, and it is used for welded structural parts of bridges and buildings.
Compared with ordinary carbon steel, weathering steel has better corrosion resistance in the atmosphere. Compared with ordinary stainless steel, weathering steel is rich in trace alloying elements, such as phosphorus, copper, nickel, vanadium, titanium, etc., alloying elements The total amount is only a few percent of the total content, while stainless steel can reach more than ten percent, so the price is cheaper than ordinary stainless steel.
|
No |
Standard |
Material |
|
1 |
ASTM standard |
Corten A/Corten B/A588 GR.A /A588 GR.B /A242 |
|
2 |
EN standard |
S355J0W / S355J2W / S355J0WP / S355J2WP / S355K2G1W / S355K2G2W |
|
3 |
JIS standard |
G3125 SPA-H / SPA-C ; G3114 SMA400AW / BW / CW; G3114 SMA490AW / BW |
|
4 |
GB standard |
09CuPCrNi-A,09CuP, 09CuPCrNiA, 09CrCuSb |
| Product Name | Corten Sheet plate |
| Place of Origin | China |
| Application | construction railway vehicle bridge tower |
| Alloy Or Not | Non-Alloy |
| Thickness | 1-200mm or as required |
| Standard | ASTM,EN,DIN,ANSI,BS |
| Length | 3000-12000mm as required |
| Technique | hot rolled cold rolled (as custom's request) |
| Surface Treatment | Clean, finishing,blasting cording to customer requirement |
| Tolerance | ±1% |
| Processing Services | Welding, Punching, Cutting,Decoiling |
| Invoicing | by theoretical weight |
| Delivery Time | Within 5-7 working days |
| Packing | Standard Packing |
Chemical components
|
Grade |
C |
Si |
Mn |
P |
S |
Cu |
Cr |
Ni |
|
Q235NH |
0.13
|
0.10-0.40 |
0.20-0.60 |
0.03 |
0.030 |
0.25-0.55 |
0.40-0.80 |
0.65 |
|
Q295NH |
0.15
|
0.10-0.50 |
0.30-1.00 |
0.03 |
0.030 |
0.25-0.55 |
0.40-0.80 |
0.65 |
|
Q355NH |
0.16
|
0.5 |
0.50-1.50 |
0.03 |
0.030 |
0.25-0.55 |
0.40-0.80 |
0.65 |
|
Q415NH |
0.12
|
0.65 |
1.10 |
0.025 |
0.030 |
0.20-0.55 |
0.30-1.25 |
0.12-0.65 |
|
Q460NH |
0.12
|
0.65 |
1.50 |
0.025 |
0.030 |
0.20-0.55 |
0.30-1.25 |
0.12-0.65 |
|
Q500NH |
0.12
|
0.65 |
2.0 |
0.025 |
0.030 |
0.20-0.55 |
0.30-1.25 |
0.12-0.65 |
|
Q550NH |
0.12 |
0.65 |
2.0 |
0.025 |
0.030 |
0.20-0.55 |
0.30-1.25 |
0.12-0.65 |
|
Q265GNH |
0.12
|
0.10-0.40 |
0.20-0.50 |
0.07-0.12 |
0.020 |
0.2-0.45 |
0.30-0.65 |
0.25-0.50 |
|
Q295GNH |
0.12 |
0.10-0.40 |
0.20-0.50 |
0.07-0.12 |
0.020 |
0.25-0.45 |
0.30-0.65 |
0.25-0.50 |
|
Q310GNH |
0.12 |
0.25-0.75 |
0.20-0.50 |
0.07-0.12 |
0.020 |
0.25-0.55 |
0.30-1.25 |
0.65 |
|
Q355GNH |
0.12 |
0.20-0.75 |
1.00 |
0.07-0.15 |
0.020 |
0.25-0.55 |
0.30-1.25 |
0.65 |
|
Q345GNHL |
0.12 |
0.25-0.75 |
0.20-0.50 |
0.07-0.15 |
0.035 |
0.25-0.55 |
0.30-0.65 |
0.65 |
