What is S420J0?
S420J0 is a high-strength, low-alloy structural steel grade standardized under EN 10025-2.
"S" = Structural steel
"420" = Minimum yield strength of 420 MPa
"J0" = Charpy impact energy of 27 J at 0°C, providing good low-temperature toughness.
It is widely used in bridges, heavy engineering structures, cranes, and building frameworks due to its high strength, weldability, and toughness.
1. Mechanical Properties
| Property | Value / Requirement | Standard / Notes |
|---|---|---|
| Yield Strength (ReH) | ≥ 420 MPa | EN 10025-2 |
| Tensile Strength (Rm) | 520–680 MPa | EN 10025-2 |
| Elongation (A5) | ≥ 17–20% | Typical for structural steel |
| Impact Energy (Charpy V-notch) | ≥ 27 J at 0°C | "J0" rating |
| Hardness (HB) | 150–200 HB | Brinell hardness |
| Density | 7.85 g/cm³ | Standard steel value |
| Modulus of Elasticity | 210 GPa | Typical for structural steel |
2. Chemical Composition (Typical % by weight)
| Element | C | Si | Mn | P | S | N |
|---|---|---|---|---|---|---|
| % | 0.22 | ≤0.55 | 1.60 | ≤0.035 | ≤0.035 | ≤0.012 |
What is S355J0?
What is S355J0?
S355J0 is a high-strength, non-alloy structural steel standardized under EN 10025-2.
"S" = Structural steel
"355" = Minimum yield strength of 355 MPa
"J0" = Charpy impact energy of 27 J at 0°C, providing good low-temperature toughness
It is widely used in bridges, building structures, and heavy engineering applications, offering excellent weldability, machinability, and moderate low-temperature performance.
1. Mechanical Properties
| Property | Value / Requirement | Standard / Notes |
|---|---|---|
| Yield Strength (ReH) | ≥ 355 MPa | EN 10025-2 |
| Tensile Strength (Rm) | 470–630 MPa | EN 10025-2 |
| Elongation (A5) | ≥ 20% | Typical for structural steel |
| Impact Energy (Charpy V-notch) | ≥ 27 J at 0°C | "J0" rating |
| Hardness (HB) | 140–190 HB | Brinell hardness |
| Density | 7.85 g/cm³ | Standard steel value |
| Modulus of Elasticity | 210 GPa | Typical for structural steel |
2. Chemical Composition (Typical % by weight)
| Element | C | Si | Mn | P | S | N |
|---|---|---|---|---|---|---|
| % | 0.22 | ≤0.55 | 1.60 | ≤0.035 | ≤0.035 | ≤0.012 |
What is the difference of them?
S420J0 vs S355J0
| Feature | S355J0 | S420J0 |
|---|---|---|
| Yield Strength (ReH) | ≥ 355 MPa | ≥ 420 MPa |
| Tensile Strength (Rm) | 470–630 MPa | 520–680 MPa |
| Impact Energy (Charpy V) | ≥ 27 J at 0°C | ≥ 27 J at 0°C |
| Low-Temperature Use | Moderate low-temperature toughness | Moderate low-temperature toughness |
| Weldability | Excellent | Excellent |
| Typical Applications | Bridges, building frameworks, general structural steel | Bridges, heavy-duty structures, cranes, high-load applications |
Key Differences
Strength: S420J0 has higher yield and tensile strength than S355J0, allowing lighter, stronger structures for heavy-duty applications.
Applications: S355J0 is suitable for moderate structural loads, while S420J0 is preferred for high-load, heavy engineering structures.
Other Properties: Both grades share good weldability and toughness at 0°C, but S420J0's higher strength provides a better strength-to-weight ratio.
