Products Description
ABS EQ47 ship plate are mainly used to build vessels which are sailing in low temperature oceans.When rolling ABS EQ47, Tempered and Quenched shall be done for heat treatment,and low temperature impacting test have to be done under minus 40 centigree.For improve the thickness-direct steel property for shipbuilding steel plate ABS EQ47,Z-test for ABS Grade EQ47 is also necessary,our customers can choose three different classes,Z15,Z25 and Z35.
ABS Grade EQ47 Shipbuilding Steel Plate Chemical Composition and Mechanical Property
| C max | Si max | Mn | P max | S max | N max. |
|
0.20 |
0.55 | 1.70 |
0.025 |
0.025 |
0.020 |
| Yield Strength (MPa) min. | Tensile Strength (MPa) | Elongation min. % |
| 460 | 570-720 | 17 |
|
Equivalent steel grade of AB/EQ47 |
|||||||
|
DNV |
GL |
LR |
BV |
CCS |
NK |
KR |
RINA |
|
NV E460 |
GL-E460 |
LR/EH46 |
BV/E460 |
CCS/E460 |
K E47 |
R E47 |
RI/E460 |
ABS Grade EQ47 Shipbuilding Steel Plate Application
ABS Grade EQ47 ship plate is mainly used to Shipbuilding Project and Ocean Offshore Structural Project.
ABS Grade EQ47 Shipbuilding Steel Plate Other Name
ABS Grade EQ47 Shipbuilding steel plate,ABS Grade EQ47 Ship Steel plate ,ABS Grade EQ47 Marine Steel plate , ABS Grade EQ47 Steel Plate .
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Technical Requirements & Additional Services for ABS EQ47 Offshore platform Steel plate
♦ High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Cetificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user's demands
As a professional EQ47 shipbuilding steel plate supplier, we promise we can offer you the qualified EQ47 shipbuilding steel plate and our EQ47 Shipbuilding and Offshore platform Steel plate price is reasonable. If you need any further information about EQ47 shipbuilding steel plate, Please feel free to contact us.
