Products Description
EN S960QL steel is high strength steel, which provides a minimum yield strength of up to 960 MPa depends on thickness.
EN S960QL steel is usually used for applications where mobile or fixed structures have to carry high loads – often in safety critical situations.
EN S960QL steel enables engineering companies to save significant weight in what they are building.
Grade 960QL is a high strength structural steel in the quenched and tempered condition which gives the material excellent strength and abrasion resistance.
- Grade Designation
- S = Structural Steel
- 960 = minimum yield strength (MPa)
- Q = Quenching & Tempering
- L = Low notch toughness testing temperature
Chemical Composition of S960QL
| Chemical Composition | % |
|---|---|
| C | 0.20 |
| Si | 0.80 |
| Mn | 1.70 |
| P | 0.020 |
| S | 0.010 |
| N | 0.015 |
| B | 0.0050 |
| Cr | 1.50 |
| Cu | 0.50 |
| Mo | 0.70 |
| Nb | 0.06 |
| Ni | 2.0 |
| Ti | 0.05 |
| V | 0.12 |
| Zr | 0.15 |
Mechanical Properties of S960QL
| Designation | Mechanical Properties (ambient temperature) | |||||||
|---|---|---|---|---|---|---|---|---|
| Steel Name | Steel Number | Min. Yield Strength ReH MPa | Tensile Strength Rm MPa | Min. & elongation after fracture | ||||
| Nominal thickness (mm) | Nominal thickness (mm) | |||||||
| >3 <50 | >50 <100 | >100 <150 | >3 <50 | >50 <100 | >100 <150 | |||
| S960QL | 1.8933 | 960 | -- | -- | 980/1150 | -- | -- | 10 |
EN S960QL steel equivalent grades
| EU | Germany | France |
| EN | DIN,WNr | AFNOR |
| S960QL | TStE960V | E960T |
| S960T |
EN S960QL steel gets its strength from being quenched and tempered. The low temperature impact test of EN S960QL steel shall be done at minus 40 centi degree with minimum 27J energy on transverse direction.
EN S960QL steel is widely used in the manufacture of more than 100 tons of mining car floor, pumping machinery, excavators, truck cranes, crawler cranes, coal mine hydraulic supports, etc.
Email: info@gneesteels.com
Whatsapp (WeChat) :+86 15824687445
FAQ
Q: What is the equivalent of S960ql?
A: What are S960ql Equivalent Astm? S960ql is a high-strength structural grade. The ASTM S960ql Equivalent is the ASTM Q345 exhibiting outstanding low temperature and cold stamping properties.
Q: What is the yield strength of S960ql?
A: High Yield Strength: S960 steel has a minimum yield strength of 960 MPa, which is significantly higher than standard structural steels. This exceptional strength allows for the construction of lighter and more efficient structures.
